LP-Y32 Hydraulic Punch Jewelry Stamping Press Machine

$124,200.00

Invest in the Hydraulic Punch Jewelry Stamping Press Machine and experience a new level of precision, power, and productivity in your metal forming operations. With its advanced features, robust construction, and versatile capabilities, this machine is poised to become the cornerstone of your manufacturing process, driving efficiency and quality to new heights.

Key Features:

Versatile Performance: With adjustable slide strokes ranging from 500mm to 1200mm, this machine adapts to a wide variety of stamping applications, from intricate jewelry work to robust auto parts production.
Impressive Force Range: Offering ejector forces from 160kN to 5000kN and a return force of 1000kN, the Y32 delivers the power you need for even the most challenging metal forming tasks.
Advanced Servo System: Our cutting-edge servo system ensures precise control and energy efficiency, reducing operating costs while improving output quality.
Customizable Options: Choose from various voltage options to suit your facility’s requirements, ensuring seamless integration into your existing setup.
Compact yet Powerful: With dimensions of 1000x900x2900mm and weighing 13 tons, this machine packs industrial-grade performance into a relatively compact footprint.

SKU: 45632302668 Categories: Jewelry Stamping Machine, Stamping

Description

Products Description

Item		unit	Y32-63	Y32-100	Y32-160	Y32-200	Y32-315
Nominal force		KN	630	1000	1600	2000	3150
Knockout force		KN	160	250	250	400	630
Daylight		mm	700	800	800	1120	1250
Slide stroke		mm	500	500	650	710	800
Knockout stroke		mm	200	200	200	250	300
Speed of slide	Descent	mm/s	38	38	40	80	120
	Pressing	mm/s	10	10	8	5-12	5-12
	Returm	mm/s	95	70	65	70	65
Table area	L-R	mm	550	630	800	900	1200
	F-B	mm	630	630	800	900	1200
Table hight above floor		mm	550	550	550	550	700
Overall dimension	L-R	mm	2370	2200	1150	2450	2830
	F-B	mm	900	1200	800	1300	1500
	Hight above floor	mm	2770	2800	2600	3650	4300
Motor power		kw	7.5	11	11	15	22

Item		unit	Y32-400	Y32-500	Y32-630	Y32-800	Y32-1000
Nominal force		KN	4000	5000	6300	8000	10000
Knockout force		KN	630	1000	1600	2000	2000
Daylight		mm	1250	1500	1500	1500	1600
Slide stroke		mm	800	900	900	900	1000
Knockout stroke		mm	300	360	360	360	450
Speed of slide	Descent	mm/s	100	>100	>100	>100	>150
	Pressing	mm/s	4-10	4-10	5-12	5-12	4-10
	Returm	mm/s	50	50	60	90	100
Table area	L-R	mm	1200	1400	1600	2000	2000
	F-B	mm	1200	1400	1600	1600	1800
Table hight above floor		mm	700	715	500	300	300
Overall dimension	L-R	mm	2850	3300	3600	4800	7010
	F-B	mm	1500	1500	1800	2854	3000
	Hight above floor	mm	4400	5400	5300	5400	5740
Motor power		KW	22	30	44	60	60

Item		unit	Y32-1250	Y32-1600	Y32-2000	Y32-2500	Y32-3000
Nominal force		KN	12500	16000	20000	25000	30000
Knockout force		KN	2000	2500	3150	4000	5000
Daylight		mm	1500	1600	1800	2000	2000
Slide stroke		mm	900	1000	1200	1200	1200
Knockout stroke		mm	400	450	450	500	500
Speed of slide	Descent	mm/s	>150	>150	>150	>150	>150
	Pressing	mm/s	4-10	4-10	4-10	4-10	5-12
	Returm	mm/s	85	>100	60	≥100	120
Table area	L-R	mm	2500	2500	2500	3000	4000
	F-B	mm	2000	2000	2000	2500	2600
Table hight above floor		mm	200	200	200	200	200
Overall dimension	L-R	mm	5890	6500	6870	7630	8530
	F-B	mm	3450	3900	2500	5000	4000
	Hight above floor	mm	6980	7500	7500	7840	8500
Motor power		KW	60	70	90	120	170
