LP21-200 Pneumatic Punching Coin Metal Stamping Press
$67,500.00
Upgrade your production line with the Pneumatic Punching Coin Metal Stamping Press. This powerhouse machine combines strength, precision, and efficiency to take your manufacturing capabilities to new heights.
Key Features:
- Powerful Performance: 160-200 ton pneumatic clutch-type power press
- Versatile Applications: Ideal for stamping, blanking, and piercing
- Precision Engineering: High-accuracy results for quality output
- Durable Construction: C-frame steel welded body for long-lasting use
- Advanced Technology: PLC control system for seamless operation
Description
Product Description
160ton 200ton Pneumatic clutch type Power Press for sale
Specifications:
| ITEM | CODE | UNIT | JH21-160 | JH21-200 | |
| Nominal Capacity | Pe | KN | 1600 | 2000 | |
| Slide Stroke | S | mm | 200 | 220 | |
| Slide Strokes | Fixed | spm | Times/min | 45 | 45 |
| Variable(optional) | spm | Times/min | 30-45 | 25-45 | |
| Max. Die Shut Height | H2 | mm | 400 | 450 | |
| Die Shut Height Adjustment | t | mm | 100 | 110 | |
| Throat Depth | C1 | mm | 400 | 430 | |
| Distance Between Columns | d1 | mm | 736 | 910 | |
| Slide Bottom Size | F-B | b | mm | 580 | 650 |
| L-R | a | mm | 700 | 880 | |
| Shank Hole Size | Diameter | d | mm | 70 | 70 |
| Depth | I | mm | 100 | 100 | |
| Bolster Size | F-B | D | mm | 760 | 840 |
| L-R | C | mm | 1175 | 1390 | |
| Thickness | H3 | mm | 165 | 180 | |
| Bed Opening Hole Diameter | ¢ | mm | 220 | 250 | |
| Overall Dimensions | F-B | A | mm | 2305 | 2600 |
| L-R | B | mm | 1420 | 1540 | |
| Height | H | mm | 3215 | 3800 | |
| Motor Power | KW | 15 | 18.5 | ||
| Weight(approximate) | kg | 13600 | 19200 |
Workshop
Packaging & Shipping
Additional information
| Weight | N/A |
|---|---|
| Nominal Force (kN) | 2000 |
